增速铣削电主轴

产品型号：PS-A-3

技术参数：

1. Asynchronous motor 2 poles             异步电机2极

2. Max power 3KW                                最大功率3KW

3. MAX torque 3.2Nm                            最大扭矩 3.2Nm

4. Tension 380V                                    电压380V

5. Max current 6.4 A                              最大电流6.4A

6. Max speed 24000rpm                        最大转速 24000rpm

7. N°2Ф25 front hybrid ceramic bearing         前端Ф25陶瓷轴承2组

8. Bearings lubrication by permanent grease     轴承永久性脂润滑

9. Autonomous cooling +internal liquid circuit   主轴自动单向冷却+内部循环液冷

10. Required cooling capacity 1100 watt            冷却功率1100watt

11 .Weight 11.5Kg                                 重量 11.5Kg

1-Cooling inlet （G1/8’’）         1-冷却液入口（G1/8’’）

2-Cooling outlet （G1/8’’）       2-冷却液出口（G1/8’’）

3-front pressurisation（M6）          3-前端气密（M6）

4-electric connection                        4-电气链接

Motor phases –earth – sensor NC    电机-接地-传感器

产品特点：

1.       可安装于现有机床，有效提高主轴转速，扩大机床适用范围。Install on the machine tools which have spindle, can effectively increase the speed of spindle, enlarge the machining scope.

2.       可用于金属材料和非金属材料的高速高效加工。Can use on the metals and non-metallic material high speed machining.

3.       关主零部件采用欧洲著名品牌。如：ATE电机、L+B编码器、SNFA陶瓷球轴承、OTT旋转接头、balluff传感器等。The main parts using famous brand in europe ATE motor, SNFA ceramic ball bearings, Balluff sensor

4.       前端2组陶瓷轴承，可提高刚性。 There are 2 sets Hybrid ceramic bearings, can crease the rigidity

5.       弹性套夹持刀具，精度高，适用范围广。Tool holder by Collects, high accuracy, fit for different machining.

6.       主轴自动单向冷却+内部循环液冷，冷却效率高。Cooling by internal liquid circuit with high cooling efficiency .

7.       可选采用HSK、ISO7:24刀柄形式。Tool holder HSK、ISO7:24

8.       轴承永久性脂润滑，免维护。Hybrid ceramic bearings greased by permanent grease without any kind of maintenance

9.       采用自冷方式电机冷却，即使重切削也不需要液冷。

Autonomous cooling by internal fan, don’t need liquid to cooling the motor.

产品图纸：

 如需查看图纸,请点击http://www.greatwalltrade.com/tz/791-00.pdf
