PS电主轴展品信息

产品型号：PS-TC-1 -S

.产品各项技术参数：

1.Max speed                                       最高转速：60000r/min

2.Max torque                                      最大扭矩：0.1N.m (S1)

3.Max power                                       最大功率：0.55KW (S1)

4.Spindle's front largest diameter with cooling water jacket 主轴带电机冷却水套后前端最大安装直径：￠45mm

5.Taper of spindle runout                   轴锥孔跳动：0.002mm

6. Ø20 front hybrid ceramic bearing   主轴前端轴承最大直径为：￠20mm

7.inlet air coolant motor(6 bar) (M5)  冷却液入口(6 bar) (M5)

8.inlet air tool change (6 bar)(G1/8″)（to be used only with arrested）换刀气压入口(6 bar) (G1/8″)只用于拉刀夹紧时

9.electric connection 3phases motor-earth thermic switch(1 PTC 130) 三相电机热传感器(1 PTC 130)

产品特点：

1.       主轴关键零部件配置采用欧洲著名品牌的ATE电机、SNFA陶瓷球轴承。The main parts  using famous brand in europe ATE motor, SNFA ceramic ball bearings, Balluff sensor

2.       主轴气压松刀，松刀压力最大6bar。hydraulic pressure unclamping tool , max pressure  6bar,

3.       主轴电机采用风冷，并采用PTC130温度传感器对主轴电机进行温升监控。spindle motor adopts air cooling，with PT130 temperature sensor to check motor and the bearing temperature

4.       主轴轴承采用脂润滑。Bearings lubrication by permanent grease

产品图纸：

 如需查看图纸,请点击http://www.greatwalltrade.com/tz/734-00-03.pdf
